5. Operation

5.1 Switching the cordless speaker on and
activating Bluetooth® (Fig. 1/Item 1)
•
Push the cordless speaker onto the battery
until it snaps into place.
•
To switch the cordless speaker on, press and
hold the On/Off switch (1) until you hear the
start signal.
•
The cordless speaker is now switched on and
Bluetooth® is activated.
•
Activate Bluetooth® on your smartphone or
tablet PC and link it with "PXC Speaker".
•
Once the connection has been established,
the speaker can be used.
•
To switch the cordless speaker off, press and
hold the On/Off switch (1) until you hear the
off signal.
Important! If the device fails to switch on, press
the switch for the battery charge level indicator (d)
on the rechargeable battery and try again (Fig. 4).
5.2 Operating the activated cordless speaker
(Fig. 1/Items 1, 2, 3)
Reduce volume:
press the - button (2) once briefl y
Increase volume:
press the + button (3) once briefl y
Previous title:
press the - button (2) once for a few seconds
Next title:
press the + button (3) once for a few seconds
Mute:
press the On/Off switch (1) once briefl y
5.3 Charging using the USB output (Fig. 1/
Item 4)
Important! The USB port is only suitable for
charging and cannot transfer any audio fi les
•
Push the cordless speaker onto the battery
until it snaps into place.
•
Connect the device that is to be charged to
the USB output (4) of the cordless speaker
using a suitable USB cable.
•
To activate the USB output (4), press the On/
Off switch for the USB output (6) briefly. It will
then light up blue.
•
Deactivate the USB output (4) by holding the
On/Off switch for the USB output (6) down
until it goes out.
•
If no device is connected, the USB output (4)
will be deactivated after approx. 3 min., and
the On/Off switch for the USB output (6) will
Anl_TC_SR_18_Li_BT_Solo_SPK9.indb 16 Anl_TC_SR_18_Li_BT_Solo_SPK9.indb 16
GB
go out.
5.4 Using the AUX connection (Fig. 1/Item 5)
Connect the smartphone or tablet PC from which
you want to play back audio fi les to the AUX input
(5) on the cordless speaker using an AUX cable
(3.5 mm jack plug).
Important! Using the AUX and USB ports with
the same device at the same time will adversely
aff ect the sound quality and is therefore not re-
commended.
5.5 Charging the Li battery pack (Fig. 2-3)
1. Remove the battery pack (a) from the device
by pressing the pushlock button (b) down-
wards.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(c) into the socket outlet. The green LED will
then begin to fl ash.
3. Push the battery pack onto the battery char-
ger.
In section 9 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit
If the battery pack still fails to charge, send
•
the charger
•
and the battery pack
to our customer service center.
To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
5.6 Battery charge level indicator (Fig. 4)
Press the button for the battery charge level indi-
cator (d). The battery charge level indicator (e) will
indicate the charge status of the battery by means
