Connection schematic with scart cable

Connecting a digital audio receiver

If you would like to use 5-channel audio transmis-
sion (Dolby Digital Sound/AC3), you must connect
your digital audio receiver to the DVBT 4538 recei-
ver's coaxial output.
Attention!
Note the specifications for connecting in the ope-
rating instructions supplied with your digital audio
receiver.
16.04.2009
The coaxial cable is not included in delivery.
Connect the coaxial cable to the „DIGITAL
AUDIO" port at the receiver.
Connect the coaxial cable to the digital audio
receiver.
