Mobiler Datenträger ID 40/MDT… 3 842 546 315/2007-11 Mobile data tag ID 40/MDT… Replaces: – 移动数据标签 ID 40/MDT… DE+EN+ZH Montageanleitung • Assembly instructions • 安装说明书 Abmessungen/Montage Bohrbilder Dimensions/Assembly Drilling plans 尺寸/安装 安装孔图 3 842 406 150 WT 1 3 842 406 160 3 842 406 170 Fig.
Seite 2
ID 40 | 3 842 546 315/2007-11 Bosch Rexroth AG Montage des ID 40/MDT mit Metallhalterung Assembly of the ID 40/MDT with metal support 用金属支架安装 ID 40/MDT 3 842 535 740 3 842 535 740 3 842 535 740 WT 1/S...
Seite 3
3 842 546 315/2007-11 | ID 40 Bosch Rexroth AG Integration des ID 40/MDT in Systeme mit ID 80-E/SLK oder ID 80-E/SLS Integration of ID 40/MDT into systems with ID 80-E/SLK or ID 80-E/SLS 把 ID 40/MDT 装入带 ID 80-E/SLK 或 ID 80-E/SLS 的系统...
Seite 4
ID 40 ID 40 | 3 842 546 315/2007-11 Bosch Rexroth AG Datenübertragungsbereich ID 40/MDT und ID 40/SLK Data transmission area ID 40/MDT and ID 40/SLK ID 40/MDT 和 ID 40/SLK 的数据传递范围 Fig. 8a Fig. 8b Fig. 8c Einbau in Metall Installation in metal 安装在金属件中...
