PART NAMES

MAIN UNIT

(FRONT)
1
3
4
5
(BACK)
8
2
6
7
12
9
11
10
1
Operation Panel
2 Air Outlet (Front / Back)
3
Cleanliness Monitor
4 Front Display
5
Main Unit
6 Handle (2 locations: Left and Right)
7
Front Louver
8
Back Panel (Pre-Filter)
9 Air Inlet
10
Deodorizing Filter
11 HEPA Filter
Sensor Filter
Sensor (Internal)
12
Odour / Dust (sensitive) / Temperature* /
Humidity* (* FP-J80EU)
Unit*
13
(Plasmacluster Ion Generating Unit)
14 Unit* Holder
15
Unit* Cover
16
Unit* Cleaning Brush
17
Power Cord, Plug
* The Unit refers to Plasmacluster Ion Generating Unit.
