5. Technical data

Asynchronous motor:
Power rating:
Temporary operation:
Idle speed n0:
Carbide blade:
Number of teeth:
Size of table w/o width extension:
Table width extension:
Cutting height max.:
Height adjustment, infinitely variable:
Tilting motor
Vacuum extraction socket:
6. Before putting the machine into
operation
The machine has to be set up where it can stand
firmly, e.g. on a work bench, or it must be bolted
to a strong stand.
All the covers and safety devices have to be
properly fitted before the machine is switched
on.
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine's moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
7. Assembly
Important! Be sure to pull out the power plug
before performing any maintenance and/or
conversion work on the circular saw.
7.1 Putting up the table width extension (Fig. 1)
The table width extension (21) can be hooked
onto the left and right-hand side of the saw table
(1).
Swing down the table supports (13).
Adjust the knurled screw (19) until the table
width extension (21) is level with the saw table
(1).
Insert the cross stop (8) in the runner slot (a) of
the saw table (1).
