Additional information
Problem
• No sound.
•An error message "The device
cannot be operated. Please check
the connection." appears.
OTHER
• POWER ON indicator or
STANDBY indicator is quickly
flashing.
If the following error codes appear on the screen, check the corresponding items in the table.
Code
SD04 and SD11
SD05
Downloaded from www.Manualslib.com
Possible solution
• Check if the connections are properly made between the plasma television and the device that
supports the HDMI Control functions. (See page 66.)
• Check if you have entered the settings properly for "HDMI Control Setting". (See page 68.)
• Check if you have an HDMI controlled AV system connected to one HDMI terminal and the
recorder or player connected to another HDMI terminal on the plasma television. When
connected this way, audio out from the recorder/player does not go through the plasma television
SPDIF terminal resulting in no sound to the AV system. When using an AV system and recorder
or player, be sure to connect the recorder or player to the AV system input terminal.
• Check if the connections are properly made between the plasma television and the device that
supports the HDMI Control functions. (See page 66.)
• Check if you have entered the settings properly for "HDMI Control Setting". (See page 68.)
• Internal protective circuits may have been activated. First turn off a on the plasma television, and
then turn the power on by pressing a again after waiting one minute or more. If the indicator is
still flashing, unplug the plasma television's power cord from the power outlet. Wait one to two
minutes then plug in the plasma television again. If this does not solve the problem, contact a
Pioneer Service Center. These are listed on your warranty card for each country. Alternatively,
check the Pioneer Web site (see back cover) for contact details.
Message
Powering off. Internal temperature too high.
Check temperature around PDP.
(PDP-5080XD/PDP-SX5080D)
Internal protection circuit turns the system off.
Is there a short in speaker cable?
(PDP-4280XD/PDP-SX4280D)
Internal protection circuit turns the system off.
manuals search engine
Check
Check if the ambient temperature of the plasma television is
high.
Check the speaker cable connections between the plasma
television and the speakers.
Contact a Pioneer Service Center. These are listed on your
warranty card for each country. Alternatively, check the
Pioneer Web site (see back cover) for contact details.
15
75
En
