GB
immediately.
To avoid electromagnetic interference the device
should be kept away from televisions and radios.
Packaging:
The unit is supplied in packaging to prevent it from
being damaged in transit. Retain the packaging for
later storage (e.g. in winter) of the device. If you
should nevertheless wish to dispose of the
packaging, remember that it is raw material and
can therefore be reused or can be returned to the
raw material system.
Before using
1. Always place the portable device on a firm,
horizontal footing.
2. The machine must always be in an upright
position.
3. Never tilt the device by more than 45°!
Whenever the device has been transported
(inclined positions), leave for at least one hour
before connecting to a socket outlet.
4. Connect the device to the correct socket outlet
(check the mains supply voltage).
5. In the cooling function the warm exhaust air must
be transferred outside by the exhaust air hose.
An opening in the wall or window must therefore
be provided.

2. Technical data

Coolant:
Coolant quantity
Cooling capacity*
Mains voltage
power rating*
Energy efficiency class*
Max. air throughput
Max. room size
Max. dehumidifier output (30°C/80%RH)
Fan speed levels
Area of application: "Room temperature" 18-32°C
Sound pressure level
Dimensions (WxDxH)
Net weight
* data according to EN 14511
12
26.11.2008

3. Proper use

The air-conditioning system is only designed to air-
condition dry rooms with a maximum room volume of
95 m 3 . The room volume depends on the local
conditions. Large window areas, additional heat
sources (PC, television, people, etc.), poor wall
insulation, etc. serve to reduce this room volume.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Layout
Front (Fig. 1)
1 Air outlet grille
2 Control device
3 Handle
4 Castors
Back (Fig. 2)
5 Air inlet filter
R410A 6 Air inlet
7 Opening for connection fittings for the exhaust air
780 g
hose
3700 W
8 Mains cable wraparound brackets
230 V ~ 50 Hz
9 Rubber bung for condensation water drain (in the
1418 W device)
A (EER 2.61)
Accessories (Fig. 3)
500 cbm/h
11 Exhaust air connection fittings
95 m 3
12 Bushing ring
53 l/day 13 Exhaust air hose
14 Foam material (Used for exhaust air outlet
3
through the window.)
15 Foam material (Used for exhaust air outlet
≤ 54 dB(A)
through the open window and placed in the open
762 x 356 x 534 cm section of the window. As far as possible, no
additional warm air should come into the room
37 kg
from outside.)
16 Cap for the hole in the window/wall
18 Drainage water hose
19 Activated carbon filter
Remote control
