GB
5. Working with the masonry channel
cutter (Fig. 10)
Important! The device is fitted with an overload cut-
out. The motor will cut out if overloaded. Relieve the
load on the motor immediately and allow the masonry
channel cutter to cool down for approx. 1 minute
without load.
Important! The device is suitable for dry cutting only!
Use a cable/pipe detector to check for concealed
electric cables and gas and water pipes in the wall
before you start using the masonry channel cutter.
Select the desired groove width (see 4.3) and
groove depth (see 4.4).
Important! Only ever guide the device along the
workpiece while switched on.
Place the device against the wall with the roller
(10) against the wall.
Switch on the device and then cut slowly into the
wall until the stop (7) rests against the wall.
Now you can cut the groove in the wall. Take care
with the cutting direction (a) as you do so. The
device must always be handled on a counter-
rotating basis otherwise there is a risk that it may
be forced out of the cut in an uncontrolled
manner.
Important! Cut in a straight line only. It is not
possible to cut curves.
At the end of the groove, swing the device out of
the groove before you switch it off.
You can then cut out the ridge between the two
grooves with a chisel.

6. TECHNICAL DATA

Voltage: 230V~ 50Hz
Power rating:
Idle speed:
Diamond cutting wheels:
Mounting hole:
Groove depth: 10 - 30mm
Groove width:
LWA sound power level: 103.9 dB(A)
LPA sound pressure level: 90.9 dB(A)
< 2.5 m/s 2
Vibration a :
w
Totally insulated:
Weight:
8
24.01.2005 18:34 Uhr Seite 8
7. Cleaning, maintenance and ordering
of spare parts
Always pull out the mains power plug before
starting any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep
into the device.
7.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be rep
laced by anyone but a qualified electrician.
7.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
7.4 Ordering replacement parts:
Please provide the following information on all orders
for spare parts:
Model/type of machine
Article number of the machine
ID number of the machine
Replacement part number of the required spare
part
1300W
9000min -1
125mm
22.2mm
8 - 26mm
II/
4.0 kg
