Anleitung SO 6-BS
GB
6. Charging options
Charging the lamp via the built-in power supply unit
1 transparent guard hood
2 18W fluorescent tube
3 power cable
4 power cable lid
5 solar charging socket
6 charging monitor
7 ON/OFF switch
8 handle
1. Open the lid for the power cable at the bottom of
the lamp, pull out the power cable and plug it in a
socket-outlet (230V ~ 50Hz).
2. The green LED „Charge" indicates that the
storage battery is being charged.
6
07.11.2001 15:21 Uhr Seite 6
3. When the red LED „Full" lights up, the battery is
fully charged.
It takes about 12 hours to charge the battery via
the built-in power supply unit. An integrated
overcharge cut-out makes sure that the battery is
not overloaded, i.e. the battery can be left
connected for longer than 12 hours without
suffering any damage.
Charging via the solar module
Installing the solar module and making the
connections
Choose a position for the solar module that lies
within reach of the power cable and which ideally
faces „south". A bracket is supplied to help you fix
the module in position. Adhesive tape can be used to
secure the module to the bracket. The solar module
is a fragile component - install it with care and protect
it from mechanical loads! A damaged solar module
cannot be repaired but has to be disposed of in an
environmentally responsible manner. The power
cable plug is simply inserted in the socket on the
back of the module.
Caution! The plug is non-reversible. Use no force
when inserting!
