Divar 2 | Operation Manual | Introduction

Introduction

Digital versatile recorder for security applications
The Divar is a video recording system that can record multiple camera signals
while simultaneously providing live multiscreen viewing and playback. It
combines the functionality of a digital recorder with a multiplexer and a
switcher.
The unit has comprehensive search (including smart motion search) and
playback facilities for viewing stored video. Once set up, all recording takes
place in the background without requiring operator intervention. Maximum
recording rates of 60 (NTSC) and 50 (PAL) images per second are guaranteed
with unsynchronized cameras. The recording rate and quality are selectable per
camera.
All models have extensive alarm handling functions and telemetry control.
Alarm functions include motion detection in user-definable areas of the image
on any camera input. The unit can be easily operated and programmed via the
front panel control keys and on-screen display menu system. One monitor
output provides full-screen, quad and multiscreen viewing; another spot/alarm.
A keyboard can be connected to improve the ease-of-use. An optional CD/DVD
writer can be connected for making archives locally.
Via a network, the Control Center PC-application can be used for live viewing,
playback and configuration. Six simultaneous users can control multiple Divars.
The Divar includes an authenticity check for both local and remote playback. A
dedicated PC player is provided for playback of secure video files.
ATM/POS transaction data can be recorded and viewed if the Divar has an
ATM/POS bridge unit and a license installed.
Bosch Security Systems
Versions
There are three Divar models; 6-channel, 9-channel and 16-channel, each with
various storage capacities. This manual describes the 16-channel version. Both 6-
channel and 9-channel versions operate in exactly the same way except that
fewer cameras can be connected, there are fewer camera keys and the number of
multiscreen views is reduced.
Setup
The unit is configured by an administrator. Access to the configuration functions
is normally password protected. The choices made during setup can restrict the
functions available to the operator. For example, the number of multiscreen
views can be limited.
Search and playback functions can also be password protected, so it is possible
that they are not available to the operator. All possible operator facilities are
described in this manual but some of these may not be available to you.
On-screen help
On-screen help is available for all topics. Just press the yellow ALT key
at least one second to see the help text associated with your current activity.
Press the escape key to exit help.
EN | 3
