FLM-420-I2-W Input interface module type wall-mount | Installation manual
i
NOTICE! Installation must only be performed by authorized and specialized personnel!
WARNING! Live components and stripped cable! Risk of injury from electric shock. The
!
system must be current-free during connection work.
CAUTION! Electrostatic discharge (ESD)! Electronic components could become damaged.
Ground yourself using a wrist strap or take other suitable actions.
Functional description
FLM-420-I2 Input interface modules provide three monitoring functions:
1. Monitoring a line with EOL resistor for standby or triggering (interruption/short circuit)
2. Monitoring a potential free contact for "open" and "closed" states
3. Voltage monitoring between 0 and 30 V DC.
The FLM-420-I2-W type wall-mount can be flush mounted in standard device boxes in accordance with EN 60670;
alternatively, it can be surface mounted in the FMX-IFB55-S interface box (see Figure 6 to Figure 7, page 7).
Address setting
Address setting is carried out using the 8 DIP switches and a suitable pointed object (see Figure 1 to Figure 4,
page 3 and the following tables).
It is not permitted to use different operating modes in the same loop/stub/T branch next to each other!
Address (A) Operating mode
0 Loop/stub in LSN improved version mode with automatic addressing
1 ... 254 Loop/stub/T branches in LSN improved version mode with manual addressing
255 = CL Loop/stub in LSN classic mode (address range: max. 127)
Connection (see Figure 5, page 6)
Description
LSN: a1- | b1+ | a2- | b2+
LSN-POWER: 0 V | 0 V | +24 V | +24 V
LSN-SHIELD
IN: IN1- | IN1+ | IN2- | IN2+
Technical specifications
Inputs
LSN input voltage
Max. current consumption from LSN
Contact monitoring:
•
EOL resistor
•
Total resistance of the line in standby
•
Max. current strength (current pulse)
Voltage monitoring:
•
Voltage range
•
Input resistance
•
Number of selectable thresholds
Permissible wire diameter
Cable length per input
Permissible operating temperature
Permissible storage temperature
Permissible rel. humidity
Protection class as per IEC 60529
Safety class as per IEC 60950
EMC interference immunity
EMC emitted interference
Housing material and color
Dimensions
Bosch Sicherheitssysteme GmbH
Function
LSN incoming/LSN outgoing
LSN power supply (support points to loop through)
Cable shielding (if present)
Input 1/Input 2
2, independent
15 to 33 V DC (min. to max.)
10.7 mA
Nominal, 3.9 kΩ
1.0 kΩ to 10.0 kΩ
8 mA
0 to 30 V DC
> 50 kΩ
32 (see programming software)
0.6 to 2.0 mm
max. 3 m
-20 °C ... +65 °C
-25 °C ... +80 °C
<96%, non-condensing
IP 30
II
EN 54-18, EN 50130, VDS 2540
EN 61000-6-3
ABS + PC blend, signal white (RAL 9003)
approx. 76 mm x 30 mm (Ø x H)
2
F.01U.012.986 | A3 | 2006.07
| en 11
