1. Overview

1 Operating panel
2 Protective grid of air outlet
3 Base
4 Safety switch
5 Compartment for remote control
6 Handle
7 Protective grid of air inlet
8 Temperature sensor
9 Main switch
10 Display
11 Standby button
12 + Increase values - temperature/time
13 - Reduce values - temperature/time
14 Infrared receiver
15 Switch the timer on / off
16 Switch the swivel function on / off
17 Mode Set operating mode
18 Control lamp
19 Remote control
20 + Increase values - temperature/time
21 Mode Set operating mode
22 - Reduce values - temperature/time
23 Standby button
24 Switch the timer on / off
25 Switch the swivel function on / off
26 Infrared transmitter

Display elements

27 Swivel function is switched on
28 Automatic mode: the device automatically adapts the heat output to the room temper-
ature. The device switches off automatically once the room temperature has reached
the desired temperature.
29 Low heat output: device operates at 1,000 watt
30 High heat output: device operates at 2,000 watt
31 Frost monitor is switched on
32 Running time
33 Display of the room temperature
34 Display of the set desired temperature
