• RECOMMENDED FUELS
Some conventional gasolines are being blended with
oxygenates such as alcohol or an ether compound to
meet clean air standards. Your Talon engine is
designed to operate satisfactorily on any gasoline
intended for automotive use including oxygenated
gasolines.
OPERATING INSTRUCTIONS
• SHOULDER HARNESS
Warning: ALWAYS WEAR SHOULDER HARNESS
when operating unit with a blade. Attach harness to
trimmer after starting unit and engine is running at
IDLE. Turn ENGINE OFF before disconnecting
shoulder harness.
1. Put the harness on so the shoulder strap is over
your LEFT shoulder.
2. Attache the harness clip (A) to the ring (B)
mounted on the shaft (Fig. 6A and 6B).
3. Adjust length of shoulder strap so stringhead is
parallel to the ground as it hangs from the strap.
A few practice swings without starting engine
should be made to determine correct balance.
NOTE: Detach the shoulder harness from the unit
before starting engine.
OPERATING INSTRUCTIONS
• STARTING A COLD ENGINE
NOTE: To minimize load on engine during starting
and warm-up, trim excess cutter line to 13cm (Fig.
8A).
1. Move ignition switch to the "RUN (I)" position (Fig.
7B).
2. MSB 24 Set throttle lock (C): Press the lock-off
switch (A) down and then while holding trigger (B)
at wide open position, press down and hold
throttle lock (C). Release throttle trigger (B).
Throttle trigger (B) will now remain in the fully
depressed position (Fig. 7C ).
3. Your unit is designed with a 3 position choke:
CHOKE " ", PARTIAL " ", and RUN " ". Move
choke lever to CHOKE " " position (Fig. 7d).
4. Prime the carburetor. Pump the primer bulb (A)
10 times (Fig. 5D).
5. Grip handle firmly – depress safety trigger (B) &
throttle trigger (C) to the FULL THROTTLE
position (Fig. 7E).
6. Pull starter rope out a short way until resistance
is felt (approximately 100mm) (Fig. 7F). A
smooth rapid pull is required for a strong spark.
22
20.12.2002 9:40 Uhr
7. Move choke lever to PARTIAL " " position (Fig.
8. Pull starter rope again 4 times while trigger is in
9. Once engine starts, leave in the PARTIAL " "
10. Move the choke to RUN " " position (Fig. 7H).
11. If engine fails to start, repeat steps 1 through 8.
NOTE: If engine fails to start after repeated attempts,
refer to Troubleshooting section.
NOTE: Always pull starter rope straight out. Pulling
starter at an angle will cause rope to rub against the
eyelet. This friction will cause the rope to fray and
wear more quickly. Always hold starter handle when
rope retracts. Never allow rope to snap back from
extended position. This could cause rope to snag or
fray and also damage the starter assembly.
•
1. Place trimmer on firm flat surface.
2. Move ignition switch to the "RUN (I)" position (Fig.
3. Grip handle firmly, squeeze throttle trigger to
4. Pull starter rope briskly until engine starts, but no
5. If engine does not start, please operate
•
Release throttle trigger. Let engine return to idle.
Push and hold ignition stop switch until engine stops.
Trimming Instructions
•
Before operating your unit, review ALL SAFETY
PRECAUTIONS in this manual.
WARNING / CAUTION
• IF UNFAMILIAR WITH TRIMMING techniques,
practice the procedures with ENGINE in "OFF"
position.
• ALWAYS CLEAR WORK area of debris such as
cans, bottles, rocks, etc. Striking objects can
cause serious injury to operator or bystanders and
also damage equipment. If an object is
accidentally hit, immediately TURN ENGINE OFF
Seite 22
Pull starter rope briskly 4 times.
7G).
the full throttle position
position for 10 seconds.
WARM ENGINE START
8).
FULL position.
more than 6 times.
"STARTING A COLD ENGINE" again.
TO STOP ENGINE
ADDITIONAL SAFETY PRECAUTIONS
