Slaves with binary outputs
↵
EDIT: Activate the settings menu.
Change the value.
↵ Transfer the value to the slave.
Slaves with analog inputs
↵ Acknowledge slave selection.
Chn: Select a channel.
↵
Acknowledge channel and display the value, return with ESC.
Slaves with analog outputs
↵ EDIT: Activate the settings menu.
Chn: Select a channel.
↵ Acknowledge the selected channel and display the value.
Change the value.
↵
Transfer the value to the slave.
Parameter para: Reading and writing slave parameters in Hex format
search: Find all slave addresses on the bus.
↵
The first assigned address blinks.
Select a slave.
Address blinks, parameter is displayed in hexadecimal format.
888
↵ EDIT: Open menu for reading and editing parameters.
Slaves with parameter string, e.g. analog slaves
read is displayed briefly. The parameter number appears at the left, and the respective
value at the right.
Select the desired parameter.
↵ Acknowledge the selected parameter.
Select a new parameter value.
The hex value blinks on the main display.
888
↵ Transfer the parameter to the slave.
