5. Overview
Refer to the illustrations on page 2 of this manual.
General Overview
1 45 rpm adapter
2 recording control panel
3 auto stop control switch
4 speed selector
Connection Panel
9 USB input
10
SD card slot
11
auxiliary input
6. Powering the Turntable
1. Connect the small end of the power cable to the power input of the turntable.
2. Connect the other end to a power source or the adapter. Plug the adapter into the mains.
7.

Audio Connection

This turntable has built-in speakers. You can also run the audio into your home stereo set or other stereo
source. To do so:
1. Use a standard RCA cable (not included). Plug the red and white connectors into the line outputs of
the turntable. Connect the other end to the auxiliary inputs of the selected audio set.
2. Operate the turntable as described below.
8. Operation
1. Set the speed control switch to the correct speed (33, 45 or 78 rpm).
2. Carefully place the record on the turntable. Use the 45 rpm adapter if necessary.
3. Remove the protective needle cover. Release the tone arm and move it to the desired starting point
on the record. Carefully place the needle on the record. The record will start playing.
4. Adjust the volume level with the volume control. Slide the auto stop control switch to choose the
auto stop function.
5. At the end of the record, the tone arm will stop automatically. You must manually return the tone
arm to the arm rest. Also, lock the tone arm and replace the protective needle cover.
9. USB/SD Card Function
9.1 Reading Music from USB/SD Card
1. Switch on the turntable.
2. Insert the formatted USB stick or SD card in the respective slot.
3. Press the MODE/REC button.
4. The turntable will start playing and stop automatically.
9.2 Recording onto USB/SD Card
1. Switch on the turntable.
2. Insert the formatted USB stick or SD card in the respective slot.
3. Release the tone arm and move it to the desired starting point on the record. Place the tone arm in
the cue position with the lever.
4. Press and hold the MODE/REC button for 3 to 5 seconds. The turntable will beep to indicate it has
entered the recording mode.
5. Lower the lever and carefully place the needle on the record. The record will start playing and be
recorded onto the USB stick or SD card.
6. Press and hold the MODE/REC button for 3 to 5 seconds. The turntable will beep twice to indicate it
has exited the recording mode.
V. 01 – 26/07/2016
TURNTABLE
5 LED power indicator
6 power switch/volume control
7 headphone jack
8 speaker
12 L/R RCA output
13
power input
