SOLDERING STATION

INTRODUCTION

This soldering station is temperature-controlled: sophisticated circuitry regulates the temperature between 150°C
and 450°C.
The unit is a 48W soldering station with a temperature sensor in the ceramic heating element. The heating element
is supplied with the necessary power via a safe 24V transformer, while the bit is completely isolated from the mains.
The control circuitry ensures that devices sensitive to static charges cannot be damaged during the soldering
process. The included bit consists of a copper core that is protected by a steel coating.
FRONTPANEL
BEFORE USE, INSERT THE SOLDERING IRON
HOLDER IN THE BASE AND TIGHTEN IT WITH
THE INCLUDED SCREW
1
8
9
10
3
DESCRIPTION OF THE CONTROL PANEL
1.
2.
3.
4.
5.
6.
5
7.
8.
6
9.
10. Heating element with incorporated temperature
11. Power indication LED
4
2
Heat safe rubber cable
Temperature control
Tray with sponge
Iron stand (fixed to main unit)
Bit
Bit holder
Heating indication LED
Handle
Antiskid rubber
sensor
Soldering station
7
1
11
13
