Installation

NOTE
Siemens AG 477 791 4070 76 J AA-74
SIMOVERT MASTERDRIVES
If the inverters/converters are ordered with optional functions, the optional
boards are already installed in the units when they are delivered.
It is possible to retrofit optional boards and this can be carried out by the user.
For this purpose, there are either three or up to six slots on the basic unit
depending on the type of construction for mounting the optional boards.
An exact description of installation is included with the relevant basic unit. As
the unit has to be removed and opened in order to install optional boards,
attention must be paid to the ESD measures. Please refer to the operating
instructions of the basic unit in this regard.
Generally, you can install the EB1 optional board in every slot. However, bear
in mind that a sensor board always requires slot C.
A maximum of two EB1s can be installed per unit.
Operating Instructions
Installation
3-1
