Displays
Operating display
Fault display
5-2
08.2000
LED Status
Green Flashing Fault-free net data transfer via SIMOLINK
Flashing SLB operating
Red
Flashing Data exchange with basic unit is okay
Yellow
Table 5-1 SLB operating display
LED Status
No net data exchange possible via SIMOLINK;
Green off/on
bus cable is not connected or is defective
Red off Voltage supply for SLB cut off;
replace SLB or basic unit
Yellow off/on No data exchange with the basic unit;
bus cable is not connected or is defective;
replace SLB or basic unit
Table 5-2 SLB fault display
Diagnostic information
Diagnostic information
6SE7087-6NX84-0FJ0
Operating Instructions SIMOVERT MASTERDRIVES
SLB - SIMOLINK Board
