Before first Use

Remove the unit and the accessory out of the packaging. Keep packaging
materials out of reach of children. There is risk of suffocation!

Assembling

1. Open the container clips (5) and remove the
accessory parts from the container. Insert the
motor filter (13) into the opening of the motor.
Insert the adaptor of the dust bag (7) into the
suction insert on the motor housing.
2. Close the dust bag with the dust bag clip (8).
3. Place the motor housing on the container and
connect both parts with the container clips.
4. Insert the adaptor of the suction hose (10) into the
hose insert (4). Connect the other end of the
suction hose with the tool you want to operate by
using the suitable tool adaptor
(12).
5. Connect the power plug of the
tool with the power tool socket (1)
at the rear side of the chip vac.
(the power consumption of the
power tool must not exceed
2400 W).

Using

Make sure the power tool is switched
off before connecting the power plug of the chip vac with mains supply.
The chips vac offers two operating modes.
Switch to stage I:
Switch to stage R:
Using
The unit is in continuous mode, that means, the
motor will operate permanently.
When the power tool is switched on, there is a delay
of approx. 3.5 seconds before the chip vac will also
switch on. When the power tool is switched off,
