Operation to the timer of model 10006587
The centre of the timer has 3 position slide switch:
• In the centre position (denoted by the clock symbol) the timer will switch the heater on and off at times set
by the segments. (See setting the timer below)
• The position denoted by the "I" is a timer override position, the timer will continue to run but power will be
supplied continuously to the heater, this enable the heater to be on all the time if required.
• In the position denoted by the "0", the timer continues to fun but no power is supplied to heater.
Setting the timer:
• Ensure the slide switch on the timer is at the mid positi-
on next to the clock symbol.
• Rotate the outer ring of the timer in a clockwise direction
until the current time is lined up with the arrow pointer,
(8 p.m=20) is in line with the arrow pointer.
• Set the time the heater is required to run by pulling the
segments around the outer ring forward appropriate to
the running period required. When set, the heater will
operate each day during the times programmed.
• If the heater is required to run continuously, the slide
switch on the timer should be set to the "I"
• position. If it is subsequently required to revert back to
timer operation, the slide switch on the timer should
• be set to the central position.
Note: When using the timer mode, duly consideration should be given to the fact that the heater may
come on whilst unattended.
Overheat Safety Device
Your heater is fitted with a safety device to switches off the heater in the event of overheating. It will be start to
work automatically again when the thermal cut-out cool down. If the heater fails to operate or the safety device
switches the heater off again, return heater to your nearest service center for examination or repair.
Cleaning
• Always disconnect the appliance and let it completely cool before any maintenance.
• Use a vacuum cleaner to remove dust on grilles.
• Clean the outside of the unit with a damp cloth and then dry it with a dry cloth. Never immerse the unit in
water, nor let water drip into the unit.

Cleaning and Care
