14 | English

Technical Data

Digital Detector
Article number
Maximum scanning depth*
– Ferrous metals
– Non-ferrous metals (copper)
– Live conductors 110 V/230 V (voltage applied)**
– Wood
Automatic switch-off after approx.
Operating temperature
Storage temperature
Battery
Operating life time, approx.
Weight according to EPTA-Procedure 01/2003
*depending on operating mode, material and size of the objects, as well as material and condition of the base
material
**less scanning depth for wires/conductors that are not "live"
In terms of accuracy, the measuring result can be inferior in case of unfavourable surface quality of the base
material.
Please observe the article number on the type plate of your measuring tool. The trade names of the individual meas-
uring tools may vary.

Declaration of Conformity

We declare under our sole responsibility that
the product described under „Technical Data" is
in conformity with the following standards or
standardization documents:
EN 61010-1:2001-03, EN 61326-1:2006-05,
EN 301489-3:2002-08, EN 301489-1:2008-04,
EN 300330-1:2010-02, EN 300330-2:2010-02
according to the provisions of the directives
2004/108/EC, 1999/5/EC.
Dr. Egbert Schneider
Dr. Eckerhard Strötgen
Senior Vice President
Head of Product
Engineering
Certification
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 29.04.2010
2 609 140 723 | (18.8.10)
Assembly

Inserting/Replacing the Battery

Alkali-manganese batteries are recommended
for the measuring tool.
To open the battery lid 14, press the latch 15 in
the direction of the arrow and fold up the bat-
tery lid. Insert the supplied battery. Pay atten-
tion that the polarity is correct, according to the
representation on the inside of the battery lid.
The battery indicator h always indicates the cur-
rent battery status:
Battery fully charged
Battery has 2/3 of its capacity or less
Battery has 1/3 of its capacity or less
Please change battery
If the measuring tool is not used for a long
period of time, the battery must be re-
moved. The battery can corrode or discharge
itself over long periods.
GMS 120
Professional
3 601 K81 000
120 mm
80 mm
50 mm
38 mm
5 min
–10 °C ... +50 °C
–20 °C ... +70 °C
1 x 9 V 6LR61
5 h
270 g
Bosch Power Tools
