Power supply

Fig 1.0
Fig 2.0
12
Fig 3.0
Aps230 ADVANCED PersonalScope
POWER SUPPLY
The APS230 PersonalScope is powered by
the supplied battery pack.
Adapter :
Use the included regulated adapter to
charge the battery pack (Fig. 1.0).
Choose the appropriate input plug (Fig. 2.0):
•
Snap the input plug onto the power supply
before use.
•
Slide the black switch on the power supply
to release the input plug.
Batteries :
The unit must be used with the recharge-
able battery that is mounted in the battery
compartment in advance (Fig. 3.0).
Type : 6V/1800mAh
