Grundig STC 1200 Servicehandbuch Seite 9

Connection example 1: analog processing of signals from 2 satellites
ASTRA 19°
ø
≥80cm
GRUNDIG LNC
Dual 1
H V
Lowband
to house distribution system,
max. level 106 dBµV
Connection example 2: analog an digital processing of signals from 1 satellite
ASTRA 19°
oder
EUTELSAT
GRUNDIG LNC
UNI Q 1
H V
Highband
to house distribution system,
max. level 106 dBµV
EUTELSAT
ø
≥100cm
GRUNDIG LNC
Dual 1
H V
Lowband
GA-Verteilung
max. Pegel
106 dBµV
ø
≥80cm
ASTRA
ø
≥100cm
EUTELSAT
H V
Lowband
GA-Verteilung
max. Pegel
106 dBµV
Connection example 3: analog and digital processing of signals from two satellites
ASTRA 19°
ø
≥80cm
GRUNDIG LNC
UNI Q 1
Lowband H/V
Highband H/V
Multiswitch
SVT 5/8
Technical Data of the Head Station
Cassettes (boxes) 12 plug-in locations for max. 24 output channels
Reception frequency range 950-2150MHz
4 RF inputs A, B, C,D, 9 outputs each
SAT input distributor
typ. -16 dB
Passage loss (9x)
75 Ω
Input/output impedance
Remote supply for SAT converter 18 V/1 A
Output frequency range of the RF collector 45 MHz-860 MHz, depending on the cassette used
Output level of the RF collector max. 106 dBµV
Setting range of the RF level control -20 dB
195 ... 260 V~; 50/60 Hz
Mains voltage
typ. 180 W (full y equipped, incl. remote supply for LNC's)
Power consumption
-20 °C to + 50 °C, (without humidification and dehumidification)
Admissible ambient temperature
Dimensions W x H x D 700 mm x 410 mm x 310 mm
Weight (when fully equipped) approx. 50 kg
EUTELSAT
ø
≥100cm
GRUNDIG LNC
UNI Q 1
Lowband H/V
Highband H/V
to house GA-Verteilung
max. Pegel
distribution system,
106 dBµV
max. level
106 dBµV
