About Cautions
CAUTION:
A CAUTION indicates a potential for property damage, personal injury, or death.
Attaching Casters to Your System
CAUTION:
Only trained service technicians are authorized to remove the system cover and access any
of the components inside the system. See your Product Information Guide for complete information
about safety precautions, working inside the computer, and protecting against electrostatic discharge.
To attach the caster bracket assemblies to your system, perform the following steps:
1
Disconnect the system and any attached peripherals from their electrical outlets,
and then disconnect the peripherals from the system.
CAUTION:
To avoid injury, two people should perform step 2.
2
Gently turn the system upside down.
3
Remove the four feet from the bottom of the chassis. Each foot is attached to the bottom
of the chassis by a screw. See Figure 1.
NOTE:
Retain these screws for use in step 5.
4
Slide one caster into the tabs on each foot so that the hole in the caster lines up with the hole
in the foot. See Figure 1.
5
Attach each caster assembly to the bottom of the chassis, using the screws you removed
in step 3. See Figure 1.
