Product- and functional description,
Hose connection Hose connections (ø100) on the exhaust side allow leading the dry, warm airflow under
e.g. the floor.
Dantherm recommends a max. of 5 metres hose per connection.
Heating coil The CDT 30S/40S has an incorporated heating coil of 1 kW.
When the dehumidifying process needs to speed up, the heating coil can be activated
and thereby increase the exhaust temperature.
See "User's guide", page 58 for how to activate the heating coil.
Water tank Water is collected in the water tank. Alternatively, you can also setup the dehumidifier
for permanent drainage with the adapter for hose connection (Accessories, see page
63).
When the water tank is full, the dehumidifier shuts off automatically.
See "User's guide", page 58 on how to drain the water tank.
Operation of the unit is not possible once the water tank is removed.
Illustration, This illustrates the operator control:
Display/operator
control
54
continued
Main switch
Running time meter
Fig. 4
Indicators
Continued overleaf
