CHAPTER ADJUSTMENT MENU
Only in DAB mode
DAB FMLK (Switching automatic between
DAB and FM)
When the DAB signal quality drops
significantly, it is preferred to switch and listen
to the service via FM.
Switching between DAB and FM
(DABFMLNK) can be disabled via the system
settings menu.
Note: If the AF indicator is not displayed, the
radio has not found the corresponding station
in FM and can not switch from DAB to FM
and vice versa.
DAB ANT
Select "Active" if an "Active" (pre-amplified)
antenna is connected (power supply via
coaxial antenna cable)
SCROLL
Rotate the [volume] knob to select SCROLL
(ID Tag) mode on or off.
Only in BT mode
AUTO CON
Press the [MENU] button for more than 2
seconds. Press [ ] or [
"AUTO CON". Rotate the [volume] knob
to select AUTO CON mode, select on or
off. When it is on, the device will connect
automatically to the last connected phone.
AUTO ANS
Press the [MENU] button for more than 2
seconds. Press [
"AUTO ANS". Rotate the [volume] knob to
select AUTO ANS mode, select on or off.
When it is ON, the radio will automatically
pick up the incoming call after a ring tone (4
to 5 ringings).
MIC SEL
In Default settings, the MIC SEL is set up
to"REAR".
The microphone cable is connected at
the rear of the radio, we advise you to not
disconnect the microphone cable in order to
avoid losing it.
To activate the front microphone : On the
main menu: Press and hold [MENU] button
for more than 2 seconds, then press [
] button several times to select MIC SEL and
rotate the [volume] knob to select "FRONT".
SOUND SETTING
Press the [ MENU ] button and press [
] button to select sound mode, press the
knob to confirm. First press shows current
EQ. Press [
] to display
options, rotate the knob to adjust.
EQ OFF -> BALANCE -> FADER-> LOUD
BALANCE:LEFT 1-7->CENTER->RIGHT 1-7
FADER:FRONT 1-7->CENTER->REAR 1-7
LOUD: ON/OFF
] or [ ] to display
/
/
] or [ ] button to select
EN-7

Bluetooth Functions

Pairing
Use this function to establish a connection
between the device and your mobile phone.
1. Turn on the radio.
2. Activate the Bluetooth function of your
mobile phone, keep the phone within 3
meters of the device and start searching for
Bluetooth devices.
3. After the Bluetooth module name "CT412
DAB INITIAL" appears on the pairing list of
your mobile phone, select it. At this time, a
pairing code is required. Enter pairing code
"1234", and Bluetooth pairing is processed
automatically.
After successful pairing, the BT icons will light
up at the top left of the display.
BT mode selecting
Press [SRC] button to choose BT/AUDIO
mode.
Hang up/Answer
5] to answer a call.
Press [
6] to hang up.
Press [
Dialing
1. Dial a phone number
Use your mobile phone to dial, the LCD
screen of the radio displays the dialing
information.
