Assembly and operating instructions
LiON Box & LiON Box Max charging station for e-bikes
Article:
ONgineer GmbH
Hindenburgring 9a • 32339 Espelkamp, Germany • info@ONgineer.de
Note
Read the operating instructions carefully before use and keep
them in a safe place!
If you pass on the LiÓN Box, also pass on the operating
instructions!
1. Introduction
These assembly instructions are part of the delivery. Read these instructions carefully before installation and keep them in a safe
place. This document contains important information on correct installation, connection, operation and maintenance.
If you have any questions, please contact the manufacturer. These installation instructions are also available at www.ONgineer.de.
The manufacturer is not liable for any damage caused by:
• Faulty assembly or incorrect operation
• Modifications to the product
• Damage to the product
• Use outside these assembly instructions
Follow the safety instructions!
2. Safety instructions
The attached safety instructions on the LiON Box / Box Max must be observed.
The operator is responsible for correct installation, operation and maintenance.
In the event of visible damage, the charging station must be taken out of operation and repaired
by the manufacturer.
A disconnecting device must be provided in the electrical installation.
The LiON Box / Box Max may only be operated in electrical installations with a residual
current circuit breaker in accordance with national and international regulations.
3. Manufacturer
ONgineer GmbH · Hindenburgring 9a · 32339 Espelkamp, Germany · www.ongineer.de

4. Technical data

Mains voltage
Mains frequency
Max. Input current
Number of charging
points
Max. Charging current
Max. Output current
Schuko charging point
System charging voltage [V DC]
Final charging voltage
Efficiency
Ambient temperature
LiON Box with cable winder
LiON Box Max with two plugged-in charging cables
Lion Box
LiON Box Max
[V]
220 ... 240
[Hz]
50-60
[A]
4,78
[Stk.]
2
[A]
4
[A]
4 (not internally fused)
36
[V DC]
42
[%]
94
[°C]
-25 ... +40
Failure to comply with the safety information and instructions may cause
electric shock, fire and/or serious injury.
Operating temperature
Standby power
(per DC charging point)
5,56
Height*
3
Width*
Depth
Weight
Lifetime
Protection class Housing
Shock resistance
* Excl. cable holder and plug connections
© 2022 ONgineer GmbH | 11 2022-MKT-EN
www.ONgineer.de
Lion Box
LiON Box Max
[°C]
-5 ... +40
[W]
< 1
[mm]
446
[mm]
318
[mm]
180
[kg]
7,3
[h]
20.000
IP44
IK09
6,5
IP54
