Workers best WB 550 WS Bedienungshinweise Seite 27

Assembly of the flange in the event of the use of a depressed grinding disc
Assembly of the flange in the event of the use of an even grinding disc
Test runs of new grinding discs and cut­off wheels
Let the angle grinder with the newly mounted grinding disc or cut-off wheel run idle for
at least one minute. Replace vibrating discs or wheels immediately.
Motor
During work, the motor must be well ventilated. For this reason, the ventilation openings
must always be kept clean.
Mounting the auxiliary side handle (4)
The auxiliary side handle (4) is suited for left or right-handed operation.
• For the purpose of left-handed operation, rotate the auxiliary side handle in the socket
onto the right side of the machine.
• For the purpose of right-handed operation, rotate the auxiliary side handle in the
socket onto the left side of the machine.
Make certain that the auxiliary side handle is securely attached so that it does not
unexpectedly become loose due to vibrations!
1221224_BDA Winkelschleifer WB 550 WS.indd 26 1221224_BDA Winkelschleifer WB 550 WS.indd 26
Wheel flange
Flange nut
Wheel flange
Flange nut
26
Thickness over 3 mm
Fig. 2
Thickness over 3 mm
Fig. 3
