ELECTRIC CONNECTIONS
B
K / PEDESTRIAN
KEY SELECTORS BLOCK
AND PUSH-BOTTON FLAT

POWER SUPPLY

230Vac 50 Hz
PHOTOCELLS
FIT SLIM
MECHANICAL SAFETY STRIP
28
K 2007
K 2007 CRX
AERIAL
SPARK
230Vac 40W
OPEN
M
COMMON
CLOSE
PEDESTRIAN
-
BUZZER
+
COMMON
K
STRIP
PHOTOCELLS
+
FOR ACCESSORIES SUPPLY
24Vdc 0,4A ± 15%
-
24Vdc 0,4A ± 15%
FOR AUTOTEST STRIP
+
R=2K2
LED
code AC07069
code AC07068
