1. INTRODUCTION

Thank you for purchasing the Lumatek 100W Full Spectrum supplemental LED Light Bar. This manual describes
how to install and use the light bar; please read this manual thoroughly before attempting to install or operate
any Lumatek system. If you are not comfortable with the installation of high performance lighting systems, you
should seek the services of a qualified installation professional.

2. PRODUCT DESCRIPTION

The Lumatek 100W Full Spectrum supplemental LED Light Bar is an electronic horticultural LED fixture using a
linear strip design with an intelligent remote LED driver making the fixture externally controllable & dimmable.
The 100W Full Spectrum supplemental LED Light Bar is an ultra-high performance full-cycle supplemental top
lighting solution for commercial horticulture cultivation & indoor farming, with the power and flexibility to scale
from propagation and cloning through vegetative growth to supplementing the higher light intensities in
bloom.
This versatile LED light bar has the same diodes and produces the same light quantity and spectra as the Zeus
Pro 2.9 series light bars but with its own separate 100W remote driver enabling the slim design light bar to be
positioned more flexibly for wider applications.
The 100W light bar can be used for the propagation of seeds and clones in a 140 x 25cm area or as a supple-
mental grow light to fill in areas around existing LED systems or even to boost yield with HID systems.
In this manual the Lumatek 100W Full Spectrum supplemental LED Light Bar will be referred to as: "the LED
fixture".

3. PRODUCT INFORMATION AND SPECIFICATIONS

3.1 General Product Information

PRODUCT NAME
PRODUCT CODE
MANUFACTURER
EAN
PLUG TYPE

3.2 Technical Specifications

PPF
EFFICACY
SPECTRUM
LIGHT SOURCE
DIMENSIONS
WEIGHT
LIFE SPAN
WORKING TEMPERATURE
WORKING HUMIDITY
WATERPROOF/DUSTPROOF
BEAM ANGLE
MANUAL DIM/
EXTERNAL LIGHTING
100W Full Spectrum supplemental LED Light Bar
LUMLED012
Lumatek Ltd
5060560031215
UK/EU
295 µmol/s
Up to 2.9 μmol/J
Full spectrum F
Higher spec LUMILEDS (W)& Osram (R) LED
1148 x 20 x 53mm
1.1Kg
60000H
-20º -- +40ºC
20% - 90%
IP65
120º
0-10V signal protocol
