HDA 4000 ATEX, IECEx intrinsically safe, increased safety, for hydrogen applications - SIL 2 / PLd
30.2

Model code for measuring ranges in psi

Accuracy
4 = 1 % FS max.
Mechanical connection
7 = 0.5 % FS max.
Mechanical connection
C = SF250CX20, Autoclave (7/16-20 UNF 2B)
G = G¼ B DIN EN 837
Electrical connection
5 = plug connector, EN175301-803, 3 pole + PE
6 = plug connector, M 12 x 1, 4 pole
9 = 1/2-14 NPT Conduit (male thread), single leads
Output signal
A = 4 .. 20 mA, 2 conductor
Measuring ranges in psi
Indication: 4-digit or 5-digit
Approval
E = ATEX, IECEx (see also certificates)
Insulation voltage
H = 500 V AC to housing
N = 50 V AC to housing
Types of protection and application areas
ATEX
I M1 Ex ia I Ma
II 1G Ex ia IIC T6, T5, T4 Ga
1 = II 1/2G Ex ia IIC T6, T5, T4 Ga/Gb
II 2G Ex ia IIC T6, T5, T4 Gb
II 1D Ex ia IIIC T
200
9 = II 3G Ex ec IIC T6, T5, T4 Gc
II 3G Ex ic IIC T6, T5, T4 Gc
C =
II 3D Ex ic IIIC T85 °C, T95 °C, T105 °C Dc
Functional Safety
S2PD = SIL2 acc. to EN 61508
PLd acc. to EN ISO 13849-1
Modification number
H00 = Standard for hydrogen applications
(other numbers are used for e.g.: different pin connection, customer part number on the type
label, ...)
(psi)
Additional declaration for psi measurement ranges
Cable length
(only for electrical Conduit connector)
Indications in m or inch
1)
only in conjunction w ith electrical connection "6" and the impact protected metal safety sleeve
Edition: 2022-01-06
HDA 4 X X X - A - XXXXX - E X X - S2PD - HXX (psi) XX
85 °C/ T 95 °C/ T 105 °C
200 200
1)
HYDAC ELECTRONIC GMBH
IECEx
Ex ia I Ma
Ex ia IIC T6, T5, T4 Ga
Ex ia IIC T6, T5, T4 Ga/Gb
Ex ia IIC T6, T5, T4 Gb
Ex ia IIIC T 85 °C/ T 95 °C/ T
200 200
1
Ex ec IIC T6, T5, T4 Gc
Ex ic IIC T6, T5, T4 Gc
Ex ic IIIC T85 °C, T95 °C, T105 °C Dc
45
105 °C
200
Part no.: 670051
