BNI IOW-302-W01-K080
Network interface
5
System Functions (continued)
5.3

LED Meaning

5.3.1 Description
Only the signal with the highest priority is displayed. The
signals are listed in descending priority.
LED US
Signal
Red flashing, 3 Hz
Red, alternating with LED off in
a ratio of 10:1, 1 s period
Red, flashing, 1 Hz
Red, static
Green, alternating with LED off
in a ratio of 10:1, 1 s period
Green flashing, 1 Hz
Green, static
Tab. 5-5: LED US
LED UA
Signal
Off
Red, static
Green, static
Yellow, static
Yellow, flashing, 1 Hz
Tab. 5-6: LED UA
Port-LEDs
Port/Pin LEDs
The port LEDs are assigned to pin 2 and pin 4 as follows:
– LED 00 – Port-Pin 4
– LED 01 – Port-Pin 2
Signal
Both LEDs flashing red, 1 Hz
Red, static
Red, static
Yellow, static
Off
Tab. 5-7: Port-LEDs
26 english
Meaning
U voltage error, voltage lower than approx.: 14V
S
Voltage outside the nominal range, wireless IO-Link communication is running
Voltage outside the nominal range, the module is paired
Voltage outside nominal range, communication not available
Voltage in nominal range, wireless IO-Link communication is running
Voltage in nominal range, the module is paired
Voltage in nominal range, the module is not paired
Meaning
Voltage U not available
A
Voltage outside nominal range
Voltage in the nominal range.
Pairing button pressed
Pairing button action performed
Meaning
Short circuit of sensor supply between pin 1 and pin 3
Short circuit at output of Pin 2/4 to Pin 3
Actuator warning Pin 2/4
State of input or output pin is 1
State of input or output pin is 0
