CONTROLS & FUNCTIONS
1. DIGITAL MEDIA PLAYER
See Digital Media Player section on page 8 for
further details.
2. DSP SETTING INDICATOR
Displays the current DSP setting.
3. INPUT 1 RCA INPUT
Connect a playback device via RCA Phono.
4. INPUT 1 CONNECTION
Connect an instrument, playback device, or
other line level equipment via either 6.3mm
(1/4") Jack or XLR.
5. MIX OUT
Master output. This output sends out a
combination of all the channels that have the
volume turned up (balanced, mono summed).
6. LED INDICATORS
POWER
When lit, the power is on.
SIG
When lit, the speaker is receiving an input
signal.
CLIP
When lit, the input signal level is excessive and
should be reduced.
7. DSP SETTING SELECTOR
Selects the desired DSP setting. Use the dial
to scroll through the 5 settings. See page 9 for
further details.
8. INPUT 1 VOLUME CONTROL
Increases or decreases the volume for input 1
or the digital media player.
9. MIC/LINE SELECTOR SWITCH
Select MIC when a microphone is connected.
Select LINE when an instrument or playback
device is connected.
10. INPUT 2 VOLUME CONTROL
Increases or decreases the input 2 volume.
11. INPUT 2 CONNECTION
Connect a microphone, instrument, or playback
device via either 6.3mm Jack or XLR. Ensure
the correct setting for either mic level or line
level connections by using the mic/line selector
switch (9).
12. POWER SWITCH
Switches the product on or off.
13. VOLTAGE SWITCH
Changes the input voltage. Ensure the correct
voltage is selected for your region.
14. POWER CONNECTION
Connect the supplied power cable here.
7
