BAE LX-VS-R _ 040
Lighting for Vision Systems
Electrical connection
Pin Signal
2
3
1 +24 V DC
1
4
2 Boost:
5...24 V DC (high)/0...3 V DC (low)
Connector
M12x1,
3 − (GND)
4-pin,
4 Trigger:
A-coded
5...24 V DC (high)/0...3 V DC (low)
Operation
CAUTION
Danger of dazzling and irritation
Looking directly into the light beam may cause
temporary dazzling and eye irritation.
► Do not look directly into the light beam!
CAUTION
Hot surface
The surface of the product may become very hot during
operation and cause burns when touched.
► Do not touch the surface during operation, wait until
the product has cooled down!
Operating mode:
– Normal (Continuous operation possible)
– Boost (Continuous operation only with cooling)
Trigger
t
Tmin
U
T
Trigger
t
D on
Boost
Trigger voltage U
T
Minimum trigger time t
T min
Boost time t
B
Delay time at 5 V DC t
D on
Delay time at 5 V DC t
D off
Accessories
Accessories are not included in the scope of delivery and
must be ordered separately.
Recommended accessories can be found at
www.balluff.com on the product page.
Accesso- Type code
ries
Lens BAM AD-VS-024-M40,5x0,5/
adapter M27x0,5-1
Lens BAM AD-VS-024-M40,5x0,5/
adapter M30,5x0,5-1
www.balluff.com
t
B
t
D off
5...24 V
1 µs
1 µs...∞
1 µs
1 µs
Order
code
BAM03NL
BAM03NM
Technical Data
Additional information on directives, approvals and
standards can be found at www.balluff.com on
the product page.
Ambient conditions
Ambient temperature
Storage temperature
Protection per IEC 60529
(when threaded together)
Electrical data
Operating voltage U
b
Operating current
Current draw I
e
Power
Overheating protection
Electrical Connection
Connection
Connection type
Cable length
Polarity reversal protected
Inputs
Trigger input
Materials
Housing material
Optical Data
Optical area
Illuminance (0.1 m)
BAE LX-VS-RR040
BAE LX-VS-RI040
BAE LX-VS-RW040
Illuminance (0.2 m)
BAE LX-VS-RR040
BAE LX-VS-RI040
BAE LX-VS-RW040
Illuminance (0.3 m)
BAE LX-VS-RR040
BAE LX-VS-RI040
BAE LX-VS-RW040
Light beam angle (FWHM)
a trigger that just doubles the brightness
1)
Balluff GmbH
Schurwaldstrasse 9
73765 Neuhausen a.d.F.
Germany
Phone + 49 7158 173-0
Fax +49 7158 5010
balluff@balluff.de
−10...+50 °C
−25...+75 °C
IP20
24 V DC
1 A
≤ 0.3 A
≤ 5.5 W
yes, shutdowen at 65 °C
Connector M12x1, 4-pin
A-coded
0.3 m
yes
yes
Aluminium, black
Ø 38 / Ø 26 mm
o i
(normal/boost )
1)
5800/9500 Lux
7500/9300 µW/cm
2
1070/3050 Lux
(normal/boost )
1)
1730/2800 Lux
1070/3050 µW/cm
2
480/850 Lux
(normal/boost )
1)
810/1280 Lux
490/800 µW/cm
2
250/410 Lux
40°
english 2
