Device structure

A
B
C
D
A - LCD screen
B - Backlit buttons
C - Status LED (red/green)
D - USB port (support service only)
E - Power inlet
Never connect the unit to the USB port. The USB
port can only be used by support technicians. Any
intervention or alteration may cause malfunctions
of the e-toll payment system and result in fines
from the service provider. Telepass SpA is not
responsible for inappropriate use of the device.
20
Screen
E
A
B
C
Buttons
/
Telepass SAT | Operating instruction v. 1.11 OCT 2020 | © 2016-2020 Telepass
Battery level
Flashing: charging the battery
Axles
No. of axles set for the vehicle
Weight load
Vehicle weight set:
< less than
<= less than or equal to
> greater than
Vehicle license plate
Opens the menu/opens the
submenu/confirms settings
Back to previous menu item
Previous/following item,
increase/decrease value
