MACHINE START AND STOP

Starting the machine
1. Sit on the driver's seat (29, Fig. C) and, if it is
necessary for an easier access to the machine, push
the lever (16, Fig. B) and tilt the steering column (31,
Fig. C) forward.
2. Push the lever (16, Fig. B) forward and tilt the steering
column (31, Fig. C) forward or backward, to reach a
comfortable position. Then release the lever (16, Fig.
B) and lock the steering column.
3. Without pressing the drive pedal (5, Fig. C), turn the
ignition switch (2, Fig. B) to "II" position, then release
it; it will go back to "I" position. Check that the green
warning light (5, Fig. B) (charged battery) turns on. If
the yellow or red warning light (3 or 4, Fig. B) turns on,
turn the ignition switch back to "0" position and charge
the batteries (see the procedure in the Maintenance
chapter).
4. Disengage the parking brake according to the
following procedure:
– Press the pedal (6, Fig. C) and turn the lever (7,
Fig. C) from (7a) position to (7b) position.
– Release the pedal (6).
5. Drive the machine to the working area, by keeping the
hands on the steering wheel and pressing the pedal
(5, Fig. C).
6. The forward/reverse direction is selected with the
relevant switch (15, Fig. B) on the left control panel.
The drive speed can be adjusted from zero to
maximum speed by increasing the pressure on the
pedal (5, Fig. C).
NOTE
The seat (29, Fig. C) is equipped with a safety
sensor, which allows the machine to be driven
by pressing the pedal (5, Fig. C) only when the
operator is on the driver's seat.
146 2596 000(3)03-2016
USER MANUAL
7. Turn on the main broom and the vacuum fan by
pressing the switch (9, Fig. B) forward.
8. Turn on the vacuum system with the lever (3, Fig. C).
9. Lower the side brooms (13 and 14, Fig. C) by
lowering the lever (4).
NOTE
The side brooms (13 and 14, Fig. C) can be
lowered and lifted even when the machine is
moving. The side brooms do not rotate when
they are lifted, but they rotate when they are
lowered.
10. Start sweeping by turning the steering wheel (1, Fig.
C) and move the machine forward by pressing the
pedal (5).
Stopping the machine
1. To stop the machine, release the pedal (5, Fig. C). To
stop the machine more quickly, also press the service
brake pedal (6, Fig. C). In case of emergency, press
the emergency push-button (12, Fig. B) to
immediately stop the machine. To deactivate the
emergency push-button (12), turn it clockwise.
WARNING!
Avoid stopping the machine movement by
turning the ignition switch to "0", and avoid
pressing the emergency push-button,
before the machine has stopped by
releasing the accelerator pedal or by
pressing the brake pedal.
2. Lift the side brooms (13 and 14, Fig. C) by using the
lever (4).
3. To stop the main broom and the vacuum fan, turn the
switch (9, Fig. B) to "0" (central) position.
4. To stop the machine, turn the ignition switch (2, Fig.
B) to "0" position.
5. Engage the parking brake according to the following
procedure:
– Press the pedal (6, Fig. C) as necessary, then
engage the brake by turning the lever (7, Fig. C)
from (7b) position to (7a) position.
– Release the pedal (6).
