Körpermaße - Gemü 649 eSyDrive Betriebsanleitung

9 Abmessungen
9.2 Körpermaße
9.2.1 Stutzen DIN/EN/ISO (Code 0, 16, 17, 18, 60)
Anschlussart Stutzen DIN/EN/ISO (Code 0, 16, 17, 18, 60)
MG DN NPS c (min)
10 10 3/8"
15 1/2"
25 15 1/2"
20 3/4"
25 1"
40 32 1¼"
40 1½"
50 50 2"
Anschlussart Stutzen DIN/EN/ISO (Code 17, 60)
MG DN
10 10
15
25 15
20
25
40 32
40
50 50
Maße in mm
MG = Membrangröße
1) Anschlussart
Code 0: Stutzen DIN
Code 16: Stutzen EN 10357 Serie B, ehemals DIN 11850 Reihe 1
Code 17: Stutzen EN 10357 Serie A (ehemals DIN 11850 Reihe 2) / DIN 11866 Reihe A
Code 18: Stutzen DIN 11850 Reihe 3
Code 60: Stutzen ISO 1127 / EN 10357 Serie C / DIN 11866 Reihe B
2) Werkstoff Ventilkörper
Code 40: 1.4435 (F316L), Schmiedekörper
Code 42: 1.4435 (BN2), Schmiedekörper, Δ Fe < 0,5 %
Code C3: 1.4435, Feinguss
Code F4: 1.4539, Schmiedekörper
GEMÜ 649 eSyDrive
c
L
ød
Anschlussart
0 16 17
25,0 - 12,0 13,0
25,0 18,0 18,0 19,0
25,0 18,0 18,0 19,0
25,0 22,0 22,0 23,0
25,0 28,0 28,0 29,0
25,0 34,0 34,0 35,0
25,0 40,0 40,0 41,0
30,0 52,0 52,0 53,0
1) , Feingussmaterial (Code C3)
NPS c (min)
3/8" 25,0
1/2" 25,0
1/2" 25,0
3/4" 25,0
1" 25,0
1¼" 25,0
1½" 25,0
2" 30,0
1) , Schmiedematerial (Code 40, 42, F4)
H1
18 60
14,0 17,2 12,5
20,0 21,3 12,5
20,0 21,3 19,0
24,0 26,9 19,0
30,0 33,7 19,0
36,0 42,4 26,0
42,0 48,3 26,0
54,0 60,3 32,0
2)
ød
Anschlussart
17 60
13,0 17,2
19,0 21,3
19,0 21,3
23,0 26,9
29,0 33,7
35,0 42,4
41,0 48,3
53,0 60,3
22 / 50
2)
L
Anschlussart
0 16
108,0 - 1,0
108,0 1,5 1,0
120,0 1,5 1,0
120,0 1,5 1,0
120,0 1,5 1,0
153,0 1,5 1,0
153,0 1,5 1,0
173,0 1,5 1,0
H1 L
12,5 108,0
12,5 108,0
13,0 120,0
16,0 120,0
19,0 120,0
24,0 153,0
26,0 153,0
32,0 173,0
www.gemu-group.com
s
17 18 60
1,5 2,0 1,6
1,5 2,0 1,6
1,5 2,0 1,6
1,5 2,0 1,6
1,5 2,0 2,0
1,5 2,0 2,0
1,5 2,0 2,0
1,5 2,0 2,0
s
Anschlussart
17 60
1,5 1,6
1,5 1,6
1,5 1,6
1,5 1,6
1,5 2,0
1,5 2,0
1,5 2,0
1,5 2,0
