Translation of the original instructions
PHM output connection
Depending on the desired charging current:
choose a cable
1.
(not supplied)
Choose the corresponding cable lug
2.
crimp with an appropriate crimping tool.
3.
Recommendations on the maximum length of cables in metres, depending on their cross-section and current intensity.
6
100 120
25
15 12
35
21 17
50
29 25
70
41 34
Values given for the use of fully copper-plated cables.
7 Shrink the heat-shrinkable tubing provided.
Pass the red cable through an input cable gland + (1) of the housing.
8
And the black cable in an inlet cable gland - (2) of the housing.
Screw the cables with the screws provided in the bag (red wire at the
9 top / black wire at the bottom)
Tighten the screws well (5 Nm) .
10 Tighten the cable gland.
11 Replace the product cover.
POWER HUB MODULE
with the appropriate cross-section
(25, 35, 50, 70 mm² supplied).
140 160 180 200 220
11 9,2 8,2 7,4 ̶
15 13 11 10 9,4
21 18 16 15 13
29 26 23 21 19
(see recommendations table below)
I max (A)
240 250 260 280 300
̶ ̶ ̶ ̶ ̶
8,6 8,2 ̶ ̶ ̶
12 12 11 11 9,8
17 16 16 15 14
320 340 360 380 400
̶ ̶ ̶ ̶ ̶
̶ ̶ ̶ ̶ ̶
9,2 ̶ ̶ ̶ ̶
13 12 11 11 10
EN
.
420 440 450
̶ ̶ ̶
̶ ̶ ̶
̶ ̶ ̶
9,8 9,4 9,2
11
