GiGO
LIGHTWEIGHT-ROLLATOR
Curb climber:
ASSEMBLING INSTRUCTION
Assembling
Necessary tools:
For assembling see picture
1
2
3
1. Screw bolt
2. Plastic washer
3. Tilting aid/Curb climber
4. Space ring
Scope of delivery!
Tilting aid/Curb climber can only be assembled at the right rear wheel!
Attention, tighten screws carefully!
Subject to technical alterations
As of: 06/2013
Drive Medical GmbH & Co . KG • Leutkircher Straße 44 • D-88316 Isny/Allgäu • Germany • info@drivemedical.de • Tel.: +49 7562 9724-0 • Fax: +49 7562 9724-25
Tilting aid
4
www.drivemedical.de
2 Screw wrench Size 13
Allen key 6 mm
5. Self-locking screw
6. Cover cap
5
6
