Operating instructions
Door/Window Alarm
Item no. 1851835
Intended use
This door/window alarm is a safety product for deterring burglars. Alarm activation is accomplished via
magnetic contact.
Voltage supply is achieved via three button cells with 1.5 volts DC each.
Contact with moisture, e.g. in bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
cause hazards such as short circuiting, fire etc. Read the instructions carefully and keep them. Make this
product available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Door/window alarm
• Operating instructions
Latest operating instructions
Download the latest operating instructions via the link www.conrad.com/downloads or scan the QR code
shown. Follow the instructions on the website.
Explanation of symbols
An exclamation mark in a triangle indicates important instructions in this operating manual that
absolutely have to be observed.
The arrow symbol indicates specific tips and advice on operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety information.
If you do not follow the safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/guarantee.
a) General
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity,
moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and protect it
from any accidental use. Safe operation can no longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height can damage
the product.
• Caution! Loud alarm!
Do not expose your hearing to this alarm sound for a prolonged period of time as otherwise
your hearing may suffer severe injury!
• Consult an expert when in doubt about operation, safety or connection of the device.
• Maintenance, modifications and repairs are to be performed exclusively by an expert or at a
qualified shop.
• If you have questions which remain unanswered by these operating instructions, contact our
technical support service or other technical personnel.
b) Batteries
• Correct polarity must be observed while inserting the batteries.
• Batteries should be removed from the device if it is not used for a long period of time to
avoid damage through leaking. Leaking or damaged batteries might cause acid burns when
in contact with skin, therefore use suitable protective gloves to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do not leave batteries lying around, as there
is risk, that children or pets swallow them.
• All batteries should be replaced at the same time. Mixing old and new batteries in the device
can lead to battery leakage and device damage.
• Batteries must not be dismantled, short-circuited or thrown into fire. Never recharge non-
rechargeable batteries. There is a risk of explosion!
Battery replacement
Observe also the safety instructions in this context!
• As soon as the alarm diminishes, you must replace the button cells. To this end, open the battery
compartment on the front side as described in below illustration!
• Always replace the entire set of button cells and use only fresh batteries of the same type for replacement
e.g., 3 x LR 44! Observe the correct polarity "+" and "-" (imprinted in the battery compartment)! Afterwards
close the battery compartment!
Installation
• Attach the door/window alarm (main device) to the side of the window or door frame by means of the
adhesive tapes!
The magnetic contact must be attached to the window frame or door leaf in parallel position using the
adhesive tape! (See illustration!) The distance between these two parts must not exceed 8 mm when the
door or window is closed!
• Set the switch to "ON"! An alarm will now sound when the door or window are opened. In the position
"OFF", the door/window alarm is out of service.
Main device
On/Off switch
Battery compartment
Mounting example:
Disposal
a) Product
Electronic devices are recyclable waste and must not be disposed of in the household waste. At
the end of its service life, dispose of the product according to the relevant statutory regulations.
Remove any inserted batteries and dispose of them separately from the product.
b) Batteries
As the end user, you are required by law (Battery Ordinance) to return all used batteries;
disposal of them in the household waste is prohibited!
Contaminated batteries are labelled with this symbol to indicate that disposal in the domestic
waste is forbidden. The designations for the heavy metals involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries, e.g. below the trash icon on the left).
Used batteries can be returned to collection points in your municipality, our stores or wherever batteries
are sold.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
Operating voltage ................................. 4.5 volts DC
3 x button cells LR44
Power consumption .............................. 65 mA during alarm
3µA (standby)
Dimensions (W x H x D) ....................... 40 x 52 x 22 mm (main unit)
15 x 52 x 19 mm (magnet bar)
Weight .................................................. 36 g (without battery)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the
capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in
part, is prohibited. This publication represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE.
