Inhaltszusammenfassung für Viessmann 4172
Seite 1
Bedienungsanleitung Operation Manual 4172 H0 Doppelausleger, 5 Stück H0 Double beam, 5 pieces 1. Wichtige Hinweise / Important information ............2 2. Befestigung des Auslegers / Fastening of the beam ......... 3 3. Gewährleistung / Warranty ................4 Innovation, die bewegt!
Seite 2
- For installation in model train layouts and diora- Dioramen. mas. - Zur Montage an alles Viessmann Oberleitungs- - For mounting on all Viessmann catenary masts. masten. - For operation in dry rooms only. - Zum Betrieb in trockenen Räumen.
Seite 3
2. Befestigung des Auslegers 2. Fastening of the beam - An der Aufnahme des Doppelauslegers befinden - You can find two fastening lugs at the bracket sich zwei Befestigungslaschen (Abb. 1). (fig. 1). - Diese werden in die dafür vorgesehenen Öffnun- - Insert them into the openings of the mainline gen des Streckenmastes eingesteckt (Abb.
Seite 4
Sie bitte Kontakt mit uns auf (service@ (service@viessmann-modell.com). Please send viessmann-modell.com). Senden Sie uns den Artikel the item to the Viessmann service department for zur Kontrolle bzw. Reparatur bitte erst nach Rück- check and repair only after consultation. If we find sprache zu.
