► In case of changes in or loss of functionality, do not continue
using the product (see "Signs of changes in or loss of functional­
ity during use" in this section).
► Take any necessary measures (e.g. repair, replacement, inspec­
tion by the manufacturer's customer service, etc.).
NOTICE
Use under unallowable environmental conditions
Damage to product due to unallowable environmental conditions
► Do not expose the product to unallowable environmental condi­
tions (see the section "Environmental Conditions").
► If the product has been exposed to unallowable environmental
conditions, check it for damage.
► If damage is apparent or in case of doubt, do not continue using
the product.
► Take suitable measures if required (e. g. cleaning, repair,
replacement, inspection by the manufacturer or a specialist
workshop etc.).
Signs of changes in or loss of functionality during use
Among other factors, changes in functionality can be indicated by an
altered gait pattern, a change in the positioning of the prosthetic com­
ponents relative to each other and by the development of noises.

4 Scope of Delivery

The following single components and accessories are included in the
scope of delivery in the specified quantities and are available for
reordering according to their respective symbols as single compon­
ents ( ), single components with minimum order quantities (
single-component packs ( ):
4R72=D, 4R72=D-62, 4R75=D-70, 4R84=D, 4R84=D-62 connec­
Fi­ Item Quantity
g.
– – 1( )
1 – 1( )
Only with 4R72=D, 4R72=D-62, 4R75=D-70
– – 4(

5 Preparation for Use

CAUTION
Incorrect alignment or assembly
Injuries due to fall resulting from damaged prosthesis components
► Observe the alignment and assembly instructions.
CAUTION
Improper assembly of the screw connections
Fall due to breakage or loosening of the screw connections
► Clean the threads before every installation.
► Apply the specified installation torque values.
► Observe the instructions for securing the screw connections and
the use of the correct length.
5.1 Adjusting the adapter
CAUTION
) or
Incorrect processing of tube
Fall due to damage to the tube
► Do not clamp the tube into a vice.
► For shortening the tube, use only a tube cutter.
tion adapter
Name
Instructions for use
Adapter
) Set screw
Article
numbers
647H436
–
506G3=M8x­
12-V
Ottobock | 9
