Electrical Installation - Moehlenhoff Standard Handbuch

Electrical installation

Standard | Comfort | Comfort K2E
230 V AC / 0,2 A
ohmic load
24 V AC / 1 A
ohmic load
Thermostat
AR 20.. S2 | K2 | K2E
AR 40.. S2 | K2 | K2E
approx. 5 OEM-Actuators
A 2xxx5 / A 4xxx5
Timer
230 V AC
N
24 V AC
L2
Only neccessary for
temperature setback
L
L1
