Install the Carousel

Tip: To prevent errors, install the carousel before operating the software or powering on the autoloader.
1. Open the front door.
2. Install the carousel in the Producer III autoloader.
a. Slide the carousel straight in so that the center post slides through the slot opening of the bearing guide.
b. Rotate the carousel until the top support bearing lowers into the bearing guide.
3. Close the front door.

Remove the Carousel

Remove the carousel from the autoloader to load or unload discs.
Important! If software is currently running an operation on the autoloader, wait for the software to complete the
operation, or pause the software operation.
1. Open the front door.
2. Grasp the bottom of the carousel with two hands and lift the carousel off the carousel platter until the top support
bearing clears the bearing guide.
3. Move the carousel outward and away from the autoloader.
2000538_B
Downloaded from www.Manualslib.com
Bearing Guide
manuals search engine
Operate the Producer III Autoloader
Top Support Bearing
Center Post
