There also is a data line in the charging
cable together with the power supply lines
and is known as a CP (control pilot) line.
This line (black-white) is inserted into the
push-in terminal on the CP connection
This applies to installing the original char-
ging cable and also to replacing the char-
ging cable.
3.2 Description of power
supply interface
connections
See also Fig. 4
The connections of the mains cable are
marked with "IN". The 5 terminals on the
left have L1/L2/L3/N/PE printed on them
The connections of the charging cable are
marked with "OUT". The 5 terminals on the
right have PE/N/L1/L2/L3 printed on them
NOTE
To release the power supply connec-
tions, use an insulated flat-head
screwdriver by inserting it into the
opening for this purpose immediately
above push-in terminal.
All dimensions specified in mm.
3.3

Electricity meter

With the integrated MID-compliant power
meter, it is possible to measure power con-
sumption by loading with the Webasto Live.
The calibration date for the power meter
can be found on the type plate on the char-
5110326C_OI-II_Webasto Live
ging station, below the CE mark. When us-
ing the power meter, pay careful attention
to the country-specific legal calibration stip-
ulation.
.
4

Scope of delivery

Scope of delivery
Charging station
Charging cable with charging coupling
RFID dongle
Installation kit for wall mounting
Wall plug (8 x 50 mm, Fischer
–
UX R 8)
Screw (6 x 70, T25)
–
Screw (6 x 90, T25)
–
Washer (12 x 6.4 mm, DIN 125-A2)
–
Screw (3 x 20 mm, T10)
–
Mounting bracket
–
Cable bushing, (one is custom-
–
made)
Installation kit for charging cable:
Spiral antikink protection
–
Cable tie
–
Strain relief clamp
–
Screw (6.5 x 25 mm, T25) for
–
fastening the strain relief clamp
Scope of delivery
Operating and installation instructions
Scope of Delivery
Table 1:
5

Required tools

Amou
Tool description
nt
1
Slot-head screwdriver 0.5x3.5 mm
1
Torx screwdriver Tx25
2
Torx screwdriver Tx10
Torque wrench (range covers 5-6 Nm,
4
for Tx25)
Torque wrench (range covers 4-5 Nm,
2
for open-ended spanner size 29)
2
Drilling machine with 8 mm drill
4 Hammer
Measuring tape
2
Spirit level
1
Wire stripping tool
2
Installation tester
EV simulator with rotary field display
1
Round file
1
Combination pliers
1
6 Installation and
2
electrical connection
Observe the safety information provided
here "Safety on page 31".
Amou
nt
EN
1
Amou
nt
1
1
1
1
1
1
1
1
1
1
1
1
1
1
