CONTENTS
1 Gauge Overview and Box Contents
2 Using the Gauge
3 Getting Started
4 Connecting the Probe
5 Taking a Reading
6 Calibrating & Testing the Gauge
Calibration
7 Batching - Model T
Pb Hg
These operation instructions are a short User Guide only. A copy of both this Instruction Manual and an English language extended version are available for download on our
website elcometer.com. For the avoidance of doubt, please refer to the original English language version.
Gauge Dimensions: Integral: 168 x 73 x 37mm (6.61 x 2.87 x 1.46"); Separate: 141 x 73 x 37mm (5.55 x 2.87 x 1.46").
Gauge Weight: Integral: 218g (7.69oz) including batteries; Separate: 161g (5.68oz) including batteries.
© Elcometer Limited 2012 - 2014. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored (in a retrieval system or otherwise) or translated
into any language, in any form or by any means (electronic, mechanical, magnetic, optical, manual or otherwise) without the prior written permission of Elcometer Limited.
TMA-0523 Issue 05 - Text with cover 23302
8 Displaying Graphs
9 Menu Structure - Model T
10 Menu Structure - Model B
11 Downloading Data to PC or Mobile Apps &
Upgrading Your Gauge
12 Additional Information
13 Legal Notices & Regulatory Information
