5. Technical specifications

Input tuner
Input frequency range
DVB-C | DVB-T/T2 | DVB-S/S2/S2X
Input level
DVB-C | DVB-T/T2 | DVB-S/S2/S2X
LNB voltage
LNB current per input (max.)
Symbol rate
Input error correction
Input connector, female
Output TV channels
Output frequency range
DVB-C | DVB-T
Output channels DVB-C | DVB-T
Output level adjustable DVB-C | DVB-T
Output modulation DVB-C | DVB-T
Output transmission symbol rate
MER DVB-C | DVB-T
FFT mode DVB-T
FEC DVB-T
Output guard interval DVB-T
Output connector, female
Test port output
Data interface
Operation voltage
Power consumption
Ambient temperature range
(acc. to EN 60065)
Dimensions (W × H × D) appr.
2019-06-15 | Technical improvements, changes in design, printing- and other errors expected.
MK 8-00/MK 8-06
8 × DVB-S/S2/S2x/T/T2/C
50...898 MHz | 900...2150 MHz
49...84 dBµV | 39...84 dBµV | 43...84 dBµV
13/17 V; 22 kHz on/off; DiSEqC 1.0
150 mA
1,5...45 MS/s
automatic
8 × F
8 × DVB-C/DVB-T
109...1006 MHz | 109...862 MHz
S2...K87 | S2...K69
80...100 dBµV | 77...98 dBµV
QAM 32, 64, 128, 256 | QPSK, QAM 16, 64
1-7,5 M'Symbol sec
≥ 40 dB | ≥ 36 dB
2k, 8k
1/2, 2/3, 3/4, 5/6, 7/8
1/4, 1/8, 1/16, 1/32
1 × F
-30 dB
2 × RJ45
100...240 VAC/50...60 Hz
50 W
-10°C...+50°C
480 × 253 × 47 mm
MK 16-00/MK 16-06
16 × DVB-S/S2/S2x/T/T2/C
16 × F
16 × DVB-C/DVB-T
60 W
47
