and the battery pack is secured in the
charger before beginning operation.
■ Connect the charger to the power
supply.
■ Place the battery pack in the charger
aligning raised rib on the battery pack
with the groove in the charger.
■ Press down on the battery pack to
be sure contacts on the battery pack
engage properly with contacts in the
charger.
NOTE: After charging is complete, the
green LED will remain on until the bat-
tery pack is removed from the charger
or charger is disconnected from the
power supply.
■ The battery pack will become slightly
warm to the touch while charging.
This is normal and does not indicate
a problem.
■ Do not place the charger and battery

LED FUNCTION

CHARGER BATTERY
LED PACK
INDICATOR STATUS
Without
Power battery
pack
Hot battery
Evaluate
pack
Cold
Evaluate battery
pack
Deeply
Evaluate
discharged
Defective Defective Flashing Flashing Battery pack or charger is defective.
• If defective, try to repeat the conditions a second time by removing and reinstalling the
battery pack. If the LED status repeats a second time, try charging a different battery.
• If a different battery charges normally, dispose of the defective pack (see Maintenance
section).
• If a different battery also indicates "Defective," the charger may be defective.
Fast
Charging
charging
Full —
pack in an area of extreme heat or cold.
They will work best at normal room
temperature.
■ When batteries become fully charged,
unplug the charger from the power
supply and remove the battery pack.
■ To remove the battery pack from the
charger, depress the latches on each
side of the battery pack.
CHARGING A HOT BATTERY PACK
When using a tool continuously, the
batteries in the battery pack will become
hot. You should let a hot battery pack cool
down for approximately 30 minutes before
attempting to recharge.
RED GREEN
LED LED
ON OFF Ready to charge battery pack.
W h e n b a t t e r y p a c k r e a c h e s c o o l e d
Flashing OFF
temperature, charger begins fast charge mode.
W h e n b a t t e r y p a c k r e a c h e s w a r m e d
Flashing OFF
temperature, charger begins fast charge mode.
Charger pre-charges battery until nomal
Flashing OFF voltage is reached, then begins fast charge
mode.
ON Flashing
OFF ON
18
NOTE: The charger and battery pack
should be placed in a location where
the temperature is more than 10°C but
less than 38°C.
ACTION
—
Charging complete
