16.7.3 UL-Sicherungen und Leiterquerschnitt für Netz- und Motorkabel
Typische
Wellenleistung
Bussmann Bussmann
P2
RK1
[kW]
1 x 200-240 V
1,1 KTN-R20
1,5 KTN-R30
2,2 KTN-R40
3 KTN-R40
3,7 KTN-R60
5,5 -
7,5 -
3 x 200-240 V
0,75 KTN-R10
1,1 KTN-R20
1,5 KTN-R20
2,2 KTN-R20
3 KTN-R30
3,7 KTN-R30
5,5 KTN-R50
7,5 KTN-R50
11 KTN-R60
15 KTN-R80
18,5 KTN-R125 JKS-150
22 KTN-R125 JKS-150
30 FWX-150
37 FWX-200
45 FWX-250
3 x 380-500 V
0,55 KTS-R10
0,75 KTS-R10
1,1 KTS-R10
1,5 KTS-R10
2,2 KTS-R20
3 KTS-R20
4 KTS-R20
5,5 KTS-R30
7,5 KTS-R30
11 KTS-R40
15 KTS-R40
18,5 KTS-R50
22 KTS-R60
30 KTS-R80
37 KTS-R100 JKS-100
45 KTS-R125 JKS-150
55 KTS-R150 JKS-150
75 FWH-220
90 FWH-250
3 x 525-600 V
0,75 KTS-R10
1,1 KTS-R10
1,5 KTS-R10
2,2 KTS-R20
3 KTS-R20
4 KTS-R20
5,5 KTS-R30
7,5 KTS-R30
3 x 525-690 V
11 KTS-R-25
15 KTS-R-30
18,5 KTS-R-45
22 KTS-R-45
30 KTS-R-60
37 KTS-R-80
45 KTS-R-90
55 KTS-R-100 JKS-100
75 KTS-R125 JKS-125
90 KTS-R150 JKS-150
1)
Abgeschirmtes Motorkabel, nicht abgeschirmtes Netzkabel.
2)
American Wire Gauge (Amerikanische Norm für Leiterquerschnitte).
Sicherungstyp
Bussmann SIBA
J T RK1
- - -
- - -
- - -
- - -
- - -
- - -
- - -
JKS-10 JJN-10 5017906-010
JKS-20 JJN-20 5017906-020
JKS-20 JJN-20 5017906-020
JKS-20 JJN-20 5017906-020
JKS-30 JJN-30 5012406-032
JKS-30 JJN-30 5012406-032
JKS-50 JJN-50 5012406-050
JKS-60 JJN-60 5012406-050
JKS-60 JJN-60 5014006-063
JKS-80 JJN-80 5014006-080
JJN-125 2028220-125
JJN-125 2028220-125
- - 2028220-150
- - 2028220-200
- - 2028220-250
JKS-10 JJS-10 5017906-010
JKS-10 JJS-10 5017906-010
JKS-10 JJS-10 5017906-010
JKS-10 JJS-10 5017906-010
JKS-20 JJS-20 5017906-020
JKS-20 JJS-20 5017906-020
JKS-20 JJS-20 5017906-020
JKS-30 JJS-30 5012406-032
JKS-30 JJS-30 5012406-032
JKS-40 JJS-40 5014006-040
JKS-40 JJS-40 5014006-040
JKS-50 JJS-50 5014006-050
JKS-60 JJS-60 5014006-063
JKS-80 JJS-80 2028220-100
JJS-100 2028220-125
JJS-150 2028220-125
JJS-150 2028220-160
- - 2028220-200
- - 2028220-250
JKS-10 JJS-10 5017906-010
JKS-10 JJS-10 5017906-010
JKS-10 JJS-10 5017906-010
JKS-20 JJS-20 5017906-020
JKS-20 JJS-20 5017906-020
JKS-20 JJS-20 5017906-020
JKS-30 JJS-30 5012406-032
JKS-30 JJS-30 5012406-032
JKS-25 JJS-25 5017906-025
JKS-30 JJS-30 5017906-030
JKS-45 JJS-45 5014006-050
JKS-45 JJS-45 5014006-050
JKS-60 JJS-60 5014006-063
JKS-80 JJS-80 5014006-080
JKS-90 JJS-90 5014006-100
JJS-100 5014006-100
JJS-125 2028220-125
JJS-150 2028220-150
Littel Fuse Ferraz-Shawmut Ferraz-Shawmut
RK1 CC
- -
- -
- -
- -
- -
- -
- -
KTN-R10 ATM-R10
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R30 ATM-R30
KTN-R30 ATM-R30
KLN-R50 -
KLN-R60 -
KLN-R60 A2K-60R
KLN-R80 A2K-80R
KLN-R125 A2K-125R
KLN-R125 A2K-125R
L25S-150 A25X-150
L25S-200 A25X-200
L25S-250 A25X-250
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R30 ATM-R30
KTN-R30 ATM-R30
KLS-R40 -
KLS-R40 -
KLS-R50 -
KLS-R60 -
KLS-R80 -
KLS-R100 -
KLS-R125 -
KLS-R150 -
L50S-225 -
L50S-250 -
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R30 ATM-R30
KTN-R30 ATM-R30
KLSR025 HST25
KLSR030 HST30
KLSR045 HST45
KLSR045 HST45
KLSR060 HST60
KLSR075 HST80
KLSR090 HST90
KLSR100 HST100
KLS-125 HST125
KLS-150 HST150
Maximaler
Leiterquerschnitt
RK1
2)
[AWG]
- 10
- 7
- 7
- 7
- 7
- 7
- 2
A2K-10R 10
A2K-20R 10
A2K-20R 10
A2K-20R 10
A2K-30R 10
A2K-30R 10
A2K-50R 7
A2K-50R 7
A2K-60R 7
A2K-80R 2
A2K-125R 1/0
A2K-125R 1/0
A25X-150 1/0
A25X-200 4/0
A25X-250 250 MCM
A2K-10R 10
A2K-10R 10
A2K-10R 10
A2K-10R 10
A2K-20R 10
A2K-20R 10
A2K-20R 10
A2K-30R 10
A2K-30R 10
A6K-40R 7
A6K-40R 7
A6K-50R 7
A6K-60R 2
A6K-80R 2
A6K-100R 1/0
A6K-125R 1/0
A6K-150R 1/0
A50-P225 4/0
A50-P250 250 MCM
A2K-10R 10
A2K-10R 10
A2K-10R 10
A2K-20R 10
A2K-20R 10
A2K-20R 10
A2K-30R 10
A2K-30R 10
A6K-25R 1/0
A6K-30R 1/0
A6K-45R 1/0
A6K-45R 1/0
A6K-60R 1/0
A6K-80R 1/0
A6K-90R 1/0
A6K-100R 1/0
A6K-125R 1/0
A6K-150R 1/0
1)
