p10 GoTo User Manual
10(a) Aligning the lateral support
1
2
Your GoTo Seat will arrive like this,
1
with the lateral support aligned
to the body.
2
so that you can rotate the
lateral support.
Rotate the lateral support
3
anticlockwise and into position.
Check that the lateral support is
4
home in the central section of
the backrest, and tighten
the knob.
3
4
Turn your GoTo Seat over and clip
5
the lateral support straps into the
central buckle. See Section 11(b)
for guidance.
Check that when the lateral
support straps are clipped
together, all straps are
arranged correctly as shown.
5
